Reolink E1 Outdoor Pro, smart 8MP PTZ Dual-Band WiFi camera with spotlights
This product is no longer available. The successor is Reolink E560.
SKU
REOLINK-E1-OUTDOOR-PRO-W
This product is no longer available. The successor is Reolink E560.
Reolink E1 Outdoor Pro
- 4K/8MP Ultra HD PTZ camera with 3x optical zoom. Compared to digital zoom, optical zoom retains image quality and sharpness as the focal distance increases;
- Smart detection. Receive push notifications or email alerts on your mobile device when a person, vehicle, or pet enters the detection zone. No more unnecessary alarms;
- Two-way communication. Built-in microphone and speaker for real-time two-way talk;
- When something unusual is detected, the spotlights and siren will be automatically activated to warn intruders. You can also enable them manually;
- The camera can rotate 355° horizontally and tilt 50° vertically, covering a wider range of key areas;
- Auto-tracking. Camera automatically tracks people, vehicles and pets and records theri entire movement path. You can also manually rotate the camera via the Reolink App/Client to change the surveillance zone.
Note: Auto-tracking is available in horizontal direction only; - Three night vision modes: Black & White night vision (spotlight off), color night vision (spotlight on within a scheduled period) and smart night vision. In smart mode, the spotlight will only be activated automatically by motion at night;
- Next-Gen Dual-Band WiFi 6. WiFi 6 technology enables a faster, more stable and more secure network connection with higher bandwidth, faster connection speed and less latency, and the WPA3 security protocol. You can select 5GHz for faster, smoother live views, or stick with 2.4GHz for longer range*;
- Use indoors or outdoors. With a sturdy housing and compact structure, this 4K camera is built to withstand various harsh weather conditions, providing reliable protection (for optimum waterproof protection, please follow the instructions to install the camera);
- Super fun Time lapse videos;
- View images/videos wherever and whenever you want with free Reolink app (iOS and Android) on your smartphone or tablet;
- Flexible storage options. You can choose for storage on MicroSD card (for local storage up to 256GB, not included), FTP server or Reolink NVR.
* Note: A WiFi 6 router is recommended for optimal performance
SKU | REOLINK-E1-OUTDOOR-PRO-W |
---|---|
Brand | Reolink |
EANcode | 6975253987795 |
Model: Reolink E1 Outdoor Pro | ||
Video & Audio | Sensor | 1/2.8" CMOS Sensor |
Video Resolution | 3840x2160 (8MP) @20 frames/sec | |
Video format | H.265 | |
Lens | f=2.8~8 mm, F=1.6 | |
Field of view | Horizontal 94~50°, vertical 53~30° | |
Infrared night vision | Up to 12 meter, LED: 12st/1.6W/850nm | |
Color night vision | 4st/2.7W/6500K/180lm | |
Day/night | IR-cut filter with auto-switching | |
Audio | Two-way audio | |
Interface | Power | DC power port |
System | Reset button | |
Ethernet | One 10M/100Mbps RJ45 | |
Storage | MicroSD card slot (max 256GB) | |
Audio | Built-in microphone and speaker | |
Pan&Tilt | Pan & Tilt range | Pan: 355°, Tilt: 0~50° |
Auto Tracking | √ | |
WiFi | Wireless standard | IEEE 802.11 a/ac/ax/b/g/n |
Operating Frequency | 2.4/5 GHz | |
WiFi security | WPA/WPA2/WPA3 | |
Power | DC power | 12.0/1A, <12W |
Software features |
Frame rate | Mainstream: 2fps - 25fps (default: 20fps); Substream: 4fps - 15fps (default: 10fps) |
Code rate | Mainstream: 4096Kbps - 8192Kbps (default: 5120Kbps) Substream: 64Kbps - 512Kbps (default: 256Kbps) |
|
Browser | Edge, Chrome, Firefox, Safari | |
OS | PC: Windows, Mac OS; Smartphone: iOS, Android | |
Smart alarm | Motion detection/vehicle detection/person detection/pet detection | |
Record mode | Motion recording (default)/scheduled recording | |
Protocols & Standards | HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P | |
Max user access | Support up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 gebruikers accounts) |
|
Works with | Google Assistant | |
Working environment | Operating temperature | -10° to 50° C |
Operating humidity | 10~90% | |
Waterproof | IP64 | |
Size & weight | Dimension | Φ85x118 mm |
Weight | 415g | |
Warranty | Limited | 2-year limited warranty |
Download: specs Reolink camera's
Dimension/Specs
1. Daylight sensor; 2. 4 Spotlights; 3. Lens; 4. 12 IR LED's; 5. Status LED
