Reolink E1 Outdoor PoE, 4K 8MP PTZ camera with auto tracking and smart detection

This model is no longer available. The successor is Reolink E560P

SKU
REOLINK-E1-OUTDOOR-POE-W

This model is no longer available. The successor is Reolink E560P



Reolink E1 Outdoor PoE

Reolink E1 Outdoor PoE

  • Impressive clarity in 4K 8MP, the camera with an ultra high revolution delivers exceptionally sharp images and videos.
  • The PTZ camera can rotate with remote control, capture the finest details with optical zoom, and follow moving people/vehicles closely. Featuring pan/tilt/zoom and auto tracking, it covers a wider area and keeps focusing on the target when an event is detected
    Note: It tracks people/vehicles left and right, but not up and down
  • 3x optical zoom. The camera with a motorized varifocal lens supports 3X optical zoom. You can zoom in on details like license plates or zoom out for larger monitoring areas without distortion
  • Smart detection. The camera can distinguish people/vehicles from other things like waving branches to reduce false alarms. Never miss anything important with notifications sent to your phone when person/vehicle is detected
  • 2-way audio: With built-in mic and speaker you can talk and listen to the person standing in front of the camera
  • The camera has three night modes: black-and-white, color, and smart (motion-activated). In smart mode, its spotlights will be triggered when the camera detects a motion at night
  • With the time lapse feature, E1 Outdoor PoE makes it simple to reproduce in seconds or minutes the dynamic process of flower blossoming or the beautiful sunrise (this feature is incompatible when camera is connected to NVRs)
  • Easier installation with Power over Ethernet. With PoE technology you get simultaneous transmission of data and power via a single network cable. Less wiring, lower cost, and more conveniences.
  • View images wherever and whenever you want with free Reolink app (iOS and Android) on smartphone or tablet
  • Flexible storage options. Supports up to 256GB on Micro SD card (not included) or Reolink NVR
  • Rugged housing, withstands all kinds of weather conditions, indoors and outdoors, IP64 certified
  • Works with Google Assistant

Read more about Reolink

More Information
SKU REOLINK-E1-OUTDOOR-POE-W
Brand Reolink
EANcode 6975253980796
Model: Reolink E1 Outdoor PoE
Video & Audio Sensor 1/2.8" CMOS Sensor
Video Resolution Default: 3840x2160 (8MP) @25 frames/sec
Video format H.265
Lens f=2.8~8 mm, zoom module
Field of View Horizontal 94~50°, vertical 53~30°
Infrared night vision Up to 12 meter (LED: 12st/14mil/850nm)
Color Night Vision Up to 12 meter (LED: 4st/2.7W/6500K/180Lumens)
Day/night IR-cut filter with auto-switching
Audio Two-way audio
Interface Power DC power port
System Reset button
Ethernet One 10M/100Mbps RJ45
Storage Micro SD card slot (max 256GB)
Audio Built-in mic & speaker
Pan&Tilt
Pan&Tilt Pan: 355°, Tilt: 0° - 50°
Auto Tracking
PoE PoE  IEEE 802.3 af, 48V Active
DC Power DC 12V=1A, <12W
Software features


Frame rate Mainstream: 2fps - 25fps (default: 25fps);
Substream: 4fps - 15fps (default: 10fps)
Code rate Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps)
Browser Edge, Chrome, Firefox, Safari
OS PC: Windows, Mac OS; Smartphone: iOS, Android
Smart alarm Person detection / vehicle detection / motion detection
Record mode Motion-triggered recording (default) / scheduled / 24/7
Protocols HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Max user access Supports 12 video streams simultaneously (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts)
Works with Google Assistant
Working environment Operating temperature -10° to 50° C
Operating humidity 10~90%
Waterproof IP64
Size & weight Dimension Φ85x118 mm
Weight 395g
Warranty Limited warranty 2-year limited warranty

U kunt de specificaties downloaden als pdf. Zie Reolink camera's

Dimension/specs:

1. Daglicht Sensor;  2. Vier spotlights; 3. Lens; 4.Twaalf IR LED's; 5. Status LED
