Reolink RLC-520A, 5 MP PoE IP camera with Person/Vehicle detection
This product is no longer available. The successor is Reolink P324
SKU
RLC-520A
Related Products
Check items to add to the cart or
This product is no longer available. The successor is Reolink P324
Reolink RLC-520A
- 5 MP Super HD camera, crystal clear video with epic details
- Resolution 2560x1920
- Angle of view 80°
- Built-in microphone
- Night vision up to 30m; with 18 infrared LEDs and advanced IR technology it can see any movement clearly in the dark
- IP66 certified weatherproof
- Stunning time lapse (incompatible when camera is connected to NVR)
- Easy installation with PoE technology. The camera uses a single cable to transmit both data and power
- Real-time push notifications or alert emails to your device whenever danger is detected
- Supports to record continuously, when movement is detected or during scheduled time
- Flexible recording options: micro SD-card (up to 256 GB, not included), Reolink NVR or FTP server
| SKU | RLC-520A |
|---|---|
| Brand | Reolink |
| EANcode | 6972489771365 |
| Model: Reolink RLC-520A | ||
| Video & Audio | Sensor | 1/2.7" CMOS Sensor |
| Resolution | 2560 x 1920 (5 Megapixel) @30 frames/sec | |
| Lens | f=4.0mm fixed; F=2.0, with IR-cut filter | |
| Field of View | Horizontal: 80°, Vertical: 42° | |
| Day/night mode | Auto-switching IR-cut filter | |
| Night vision | 30 Meter (LED: 18pcs/14mil/850nm) | |
| Audio | Audio recording | |
| Video format | H.264 | |
| Power |
PoE | IEEE 802.3af, 48V |
| DC Power | DC 12.0V-1A, <12W | |
| Interface |
Ethernet | One 10M/100Mbps RJ45 |
| Storage | Micro SD-card slot (Max 256GB) | |
| System | Reset button | |
| Audio | Built-in microphone | |
| Software |
Frame rate | Mainstream: 2fps - 30fps (default: 30fps) Substream: 4fps - 15fps (default: 10fps) |
| Network protocol | HTTPS, SSL, TCP/IP, UDP, UPNP, RTSP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P | |
| Browser support | IE, Edge, Chrome, Firefox, Safari | |
| OS support | PC: Windows, Mac OS; Smart Phone: iOS, Android | |
| Max user access | 20 users (1 admin account & 19 user accounts); support up to 12 simultaneous video streams (10 substreams & 2 mainstreams) | |
| Record mode | Motion-triggered recording (default); scheduled recording | |
| Smart Alarm | Motion detection/Person detection/Vehicle detection | |
| Smart home | Google Assistant | |
| General | Environment | Operating temperature -10° ~ 55° C; Humidity 10%~90% |
| Waterproof | IP66 | |
| Dimension | F105*93mm | |
| Weight | 467,5 gr | |
Or download specs here: specs Reolink RLC-520A
