Reolink RLC-523WA, smart 5MP PTZ WiFi camera with spotlight

With person and vehicle detection, dual-band Wifi, color night vision

Reolink RLC-523WA


  • 5MP Super HD, provides you with a clearer visual quality & smoother live viewing experience
  • Dual-Band Wifi: By freely switching between 2.4 GHz and 5 GHz (5.8 GHz) frequency bands, RLC-523WA provides higher performance for camera networking and much easier network setup
  • With 2T2R MIMO antennas
  • Person and vehicle detection
  • Super clear nigh vision. The IR LEDs provide up to 60 meters night vision and its spotlights ensure color night vision
  • Time lapse. This camera makes it quicker and easier to capture the dynamic of events, with stunning effect
  • With 360° pan & 90° tilt, this PTZ camera allows you to view your world from every angle and can follow the moving person automatically
  • 5x Optical zoom for more visibility
  • Real-time, interactive communication. Built-in mic & speaker allow you to listen and talk back
  • With the on-camera technology of analyzing person and vehicle shapes, RLC-523WA offers accurate detections, and thus greatly reduces the false alarms on trivial objects’ movements
  • Remote access. With a few clicks on Reolink App or Client, you can stay tuned with your home or business all the time
  • Waterproof design: RLC-523 is designed for use in multiple scenarios. Its IP66 housing can withstand powerful water jets, intense heat, humidity and cold
  • Flexibele storage options. Videos can be saved into Micro SD card for local storage (up to 256GB), Reolink NVR or FTP server
  • Supports 24/7 continuous, motion-triggered and scheduled recording
  • Works with Google Assistant and coming soon with Amazon Alexa

Read more about Reolink.

RLC-523WA 5x optical zoom

More Information
Brand Reolink
EANcode 6972489773987
Model: Reolink RLC-523WA
Video & Audio Sensor 1/2.7" CMOS Sensor
Video Resolution 2560x1920 (5MP) @20 frames/sec
Video format H.264
Lens f=2.7~13.5 mm, F=1.6~3.3, zoom module
Field of View Horizontal 27~96°, vertical 21~69°
Infrared night vision Up to 60 meters (LED: 4st/28mil/850nm)
Color night vision Spotlights: 3st/5700K/945lumen)
Day/night IR-cut filter with auto-switching
Audio Two-way audio
Interface Power DC power port
System Reset button
Ethernet One 10M/100Mbps RJ45
Storage Micro SD card slot (max 256GB)
Audio Built-in microphone and speaker
WiFi Wireless standard IEEE 802.11 a/b/g/n
Operating frequency 2.4/5 GHz
Wireless security WPA-PSK/WPA2-PSK
Power DC power 12.0=2A, <24W
Pan&Tilt Pan&Tilt range Pan 360°, Tilt 0 ~ 90°
Pan speed 2.5°~150°/s (speed can be set)
Tilt speeid 1.5°~60°/s (speed can be set)
Preset 64
Patrol 1, up to 16 presets per patrol
Auto Tracking
Power-off memory function
Software features

Frame rate Mainstream: 2fps - 30fps (default: 20fps);
Substream: 4fps - 15fps (default: 10fps)
Code rate Mainstream: 1024Kbps - 8192Kbps (default: 4096Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps)
Browser IE, Edge, Chrome, Firefox, Safari
OS PC: Windows, Mac OS; Smartphone: iOS, Android
Smart alarm Person detection/vehicle detection/motion detection
Recording modes Motion recording (default)/scheduled recording/24/7 recording
Max user access Supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams); 20 users (1 admin account & 19 user accounts)
Works with Google Assistant
Working environment Operating temperature -10° to 55° C
Operating humidity 10~90%
Waterproof IP66
Dimension & weight Dimension Φ136x201 mm
Weight 1.8kg
Warranty Limited 2-year limited warrant


Or view specs: Reolink RLC-523WA
