Reolink RLC-823A, smart 8MP PTZ PoE Spotlight Camera with person and vehicle detection

Smart PoE camera with person & vehicle detection and auto tracking and with color night vision

SKU
RLC-823A

Reolink RLC-823A

RLC-823A

  • 8MP Ultra HD: You can easily view the hard-to-see details captured by the camera!
  • 5x Optical zoom for more visibility. With motorized varifocal lens, RLC-823A allows you to view from a wide angle. Its 5X optical zoom enables you to zoom in for astonishing details or zoom out for maximum coverage
  • Power over Ethernet - Faster, Easier & Lower-Cost Installation. Thanks to PoE technology, this PTZ IP camera can transmit videos and be charged simultaneously via only one network cable
  • Smart person/vehicle detection. RLC-823A is smart enough to distinguish person and vehicle from other objects reducing false alarms
  • Built-in siren and motion spotlight
  • RLC-823A with infrared LEDs provides  60m IR night vision & its spotlights ensure color night vision, making night scenes as vivid as day
  • Amazing time lapse videos
  • With 360° pan & 90° tilt, RLC-823A can monitor a surprisingly large area with a single security camera. It can also keep track of the moving person/vehicle automatically
  • Two-way audio. Easier communication
  • Real-tim alerts, live view from anywhere, easy & smart playback, motion zone
  • Remote access and control with Reolink App or Client
  • Waterproof design: The rugged body and housing enable this camera to withstand powerful water jets, intense heat, humidity, and the cold
  • Multiple recording options. All videos can be saved to Micro SD card (up to 256GB, not included), Reolink NVR or FTP server
  • Supports 24/7 continuous, motion-triggered, or scheduled recordings
  • Works with Google Assistant

Read more about Reolink.

RLC-823A

More Information
SKU RLC-823A
Brand Reolink
EANcode 6972489773970
Model: Reolink RLC-823A
Video & Audio Sensor 1/2.8" CMOS Sensor
Video Resolution 3840x2160 (8MP) @25 frames/sec
Video format H.265
Lens f=2.7~13.5 mm, F=1.6~3.3, zoom module
Optical zoom 5x
Field of View Horizontal 27~96°, vertical 21~69°
Infrared night vision Up to 60 meter (LED: 4st/28mil/850nm)
Color Night Vision Spotlights: 3st/5700K/945lumen)
Day/night IR-cut filter with auto-switching
Audio Two-way audio
Interface Power DC power port
System Reset button
Ethernet One 10M/100Mbps RJ45
Storage Micro SD card slot (max 256GB)
Audio Built-in microphone & speaker
PoE PoE IEEE 802.3at, 48V Active
DC power 12.0=2A, <24W
Pan&Tilt Pan&Tilt Range Pan 360°, Tilt 0 ~ 90°
Pan speed 2.5°~150°/s (speed can be set)
Tilt speed 1.5°~60°/s (speed can be set)
Preset 64
Patrol 1, up to 16 presets per patrol
Auto Tracking
'Power Off' Memory function
Software features


Frame rate Mainstream: 2fps - 30fps (default: 20fps);
Substream: 4fps - 15fps (default: 10fps)
Code rate Mainstream: 4096Kbps - 8192Kbps (default: 6144Kbps)
Substream: 64Kbps - 512Kbps (default: 256Kbps)
Browser IE, Edge, Chrome, Firefox, Safari
OS PC: Windows, Mac OS; Smartphone: iOS, Android
Smart alarm Person detection/vehicle detection/motion detection
Record mode Motion-triggered (default)/scheduled/24/7 recording
Protocols HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P, IPv4
Max user access Support up to 12 video streams simultaneous (10 substreams & 2 mainstreams);
20 users (1 admin account & 19 user accounts)
Smart Home Google Assistant
Working environment Operating temperature -10° to 55° C
Operating humidity 10~90%
Waterproof IP66
Size & weight Dimension Φ136x201 mm
Weight 1.8kg
Warranty Limited 2-year limited warranty



Afmetingen:
RLC-823A

U kunt de specificaties ook downloaden als pdf. Zie specs Reolink RLC-823A
