Tiandy TC-C32KN Spec:I3/Y/WIFI/2.8mm/V4.1, 2MP Fixed IR WiFi Dome camera
2MP WiFi outdoor security camera
SKU
TC-C32KN_I3YWIFI28V41
Related Products
Check items to add to the cart or
Tiandy TC-C32KN Spec:I3/Y/WIFI/2.8mm/V4.1
Key features
- Metal+Plastic Housing
- Resolution max 1920x1080@30fps
- Image sensor: 1/2.9" CMOS
- S+265/H.265/H.264
- Min. illumination Color: 0.02Lux@F2.0
- Smart IR, IR Range: 30m
- Built-in Mic, SD Card slot, reset button
- Support WiFi
- Operating Conditions -40°~65°, 0~95% RH
- IP66, IK10
- Field of view: 98.5 horizontal, 55.7° vertical
- Dimension: ∅120x90mm
- WiFi series
| SKU | TC-C32KN_I3YWIFI28V41 |
|---|---|
| Brand | Tiandy |
| EANcode | 6971849723945 |
| Model: TC-C32KN Spec:I3/Y/WIFI/2.8mm/V4.1 | |
| Camera | |
| Image sensor | 1/2.8" |
| Signal system | PAL/NTSC |
| Min. Illumination | Color: 0.02 Lux @ (F2.0, AGC ON); B/W: 0 Lux with IR |
| Shutter time | 1s-1/100000s |
| Day & Night | Dual IR-cut filter with auto switch |
| WDR | Digital WDR |
| Angle adjustment | Pan 0~330°, tilt 0~75°, rotate 0~350° |
| Lens | |
| Lens type | Fixed |
| Focal length | 2.8mm |
| Lens mount | M12 |
| Aperture | F2.0, fixed |
| Field of view | 98.5° (H); 55.7° (V) |
| Illuminator | |
| IR LEDs | 8 |
| IR Distance | Up to 30m |
| Wavelength | 850nm |
| White LEDs | N/A |
| Compression standard | |
| Video compression | S+265/H.265/H.264 |
| Video bit rate | 32k-6Mbps |
| Audio compression | G.711A/G.711U/ADPCM |
| Audio bit rate | 8kHz~48kHz |
| Image | |
| Max. resolution | 1920x1080 |
| Main stream | PAL: 25fps (1920×1080, 1280×720, 704x576, 640x480) NTSC: 30fps (1920×1080, 1280×720, 704x480, 640x480) |
| Sub stream | PAL: 25fps (704×576, 704×288, 352×288, 640×360) NTSC: 30fps (704×480, 704×240, 352×240, 640×360) |
| Third stream | N/A |
| ROI | N/A |
| OSD | 16x16/32x32 adaptable size, letters such as Week, Date, Time, Total 1 Region |
| Picture overlay | N/A |
| Privacy mask | Yes, 4 regions |
| Image setting | Saturation, brightness, contrast, sharpness, adjustable by client software or web browser |
| Image enhancement | BLC/3D, DNR/HLC |
| Smart defog | √ |
| Feature | |
| Alarm trigger | Motion detection, Mask alarm, IP Address conflict |
| Video analytics | N/A |
| Early Warning (EW) | N/A |
| Network | |
| Network storage | Yes (only support Tiandy ANR NVR) |
| Protocols | HTTP, TCP/IP, UDP, DHCP, RTP, RTSP, FTP, DNS, DDNS, NTP, IPv4, UPnP |
| System compatibility | ONVIF (Profile S/T/G), SDK, P2P (mutually exclusive with profile G) |
| Remote connection | ≤2 |
| Client | Easy7, EasyLive Plus |
| Web | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| WiFi | |
| Channel bandwidth | 20/40MHz |
| Wireless standard | IEEE802.11b/g/n |
| Frequancy range | 2.4 GHz ~ 2.4835 GHz |
| Protocols | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM/HT |
| Security | WPA-PSK/WPA2-PSK |
| Transfer rates | 802.11b: 11Mbps 802.11g: 54Mbps 802.11n: up to 150Mbps |
| Wireless range | Up to 50m (performance varies based on actual environment) |
| Power consumption | 802.11b: 17±1.5dBm @11Mbps 802.11g: 14±1.5dBm @54Mbps 802.11n: 12.5±1.5dBm @150Mbps |
| Interface | |
| Communication interface | 1 RJ45 10M/100M self adaptive Ethernet port |
| Audio I/O | Mic in |
| Alarm I/O | N/A |
| Reset button | √ |
| On-board storage | Built-in MicroSD card slot, up to 512GB |
| General | |
| Web client language | 19 languages Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/ Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian |
| Operating temperature | -40°C~ 65°C |
| Operating humidity | 0-95% RH |
| Power supply | DC12V±25% |
| Power consumption | Max 6W (12V) |
| Protection | Surge protection: 2000V; Lightning proof: 6000V; IP66; IK10 |
| Heater | N/A |
| Dimensions | ∅120 x 90 mm |
| Weight | 0.41 kg |
