Tiandy TC-C35WS Spec:3LRA-28, 5MP Fixed Color maker bullet camera
5MP PoE Color maker outdoor bullet camera
SKU
TC-C35WS_3LRA28-B
Related Products
Check items to add to the cart or
Tiandy TC-C35WS Spec:3LRA-28
Key features
- Metal Housing
- Up to 5MP, 3072x1728@20fps
- S+265/H.265/H.264B/M/H
- Color: 0.002Lux@(F1.6, AGC on), B/W: 0 Lux with IR
- IR Range up to 50m
- 1x Built-in Mic
- Support Human/vehicle classification
- Support micro SD/SDHC/SDXC, up to 512GB
- Operating Conditions -35°~65°, ≤95% RH
- DC12V, max 6W, PoE:IEEE 802.3af, max 7W
- IP67
- Lite series
| SKU | TC-C35WS_3LRA28-B |
|---|---|
| Brand | Tiandy |
| EANcode | 6976642045423 |
| Model: TC-C35WS Spec:3LRA28 | |
| Camera | |
| Image sensor | 1/2.7"CMOS |
| Min. Illumination | Color: 0.002 Lux @ (F1.6, AGC ON); B/W: 0 Lux with IR |
| Shutter time | 1s-1/100000s |
| Day & Night | IR-cut filter with auto switch (ICR) |
| Smart IR | Yes |
| WDR | 120dB |
| S/N | >39dB |
| Angle adjustment | 0-360°(P); 0-90°(T); 0-360°(R) |
| Lens | |
| Lens type | Fixed focal lens |
| Focal length | 2.8mm |
| Lens mount | M12 |
| Aperture range | F1.6 |
| Aperture type | Fixed |
| Field of view | 109° (H); 59° (V); 125.4° (D) |
| DORI distance | Detect: 56m Observe: 22m Recognize: 11m Identify: 5.6m |
| Illuminator | |
| IR LEDs | 2 |
| IR Distance | Up to 50m |
| Wavelength | 850nm |
| White LEDs | 2 |
| White light distance | 15m |
| Compression standard | |
| Video compression | S+265/H.265/H.264B/H.264M/H.264H |
| Video bit rate | 32k-6Mbps |
| Audio compression | G.711A/G.711U/ADPCM_D |
| Audio sampling rate | 8kHz/32kHz/48kHz |
| Image | |
| Max. resolution | 5MP, 3072x1728 @ 20fps |
| Main stream | PAL: 20fps (3072x1728), 25fps (2688x1520, 2560×1440, 2304×1296, 1920×1080, 1280×720) NTSC:20fps (3072x1728), 30fps (2688x1520, 2560x1440, 2304x1296, 1920x1080, 1280x720) |
| Sub stream | PAL: 25fps (704×576, 704×288, 352×288, 640×360) NTSC: 30fps (704×480, 704×240, 352×240, 640×360) |
| BLC | √ |
| HLC | √ |
| AGC | √ |
| 3D DNR | √ |
| White balance | Auto/Semi-auto/Manual/Sunshine/Nature light/Warmlight lamp/Daylight lamp/Filament lamp/Lock white balance |
| ROI | 8 rectangular static areas |
| OSD | Overlay of additional characters in 1 region, 1 line, with a maximum of 48 characters or 16 Chinese characters per region; 16*16/32*32/48*48/64*64/96*96; Lattice |
| Privacy mask | 4 black static areas |
| Defog | √ |
| Feature | |
| General alarm | Motion Detection; Mask Alarm; |
| Exceptions alarm | Disk full; Disk R/W Error; IP Address Conflict; Network Disconnection |
| Linkage method | Trigger recording; trigger capture; notify surveillance center |
| Video analytics | Human/Vehicle Classification; Tripwire; Perimeter; |
| Rules of behavior analyse in 1 scene | 2 |
| Network | |
| ANR | Yes |
| Protocols | RTSP; HTTP; HTTPS; TCP; UDP; UPnP; ICMP; SNMP v1/2/3; DHCP; DNS; DDNS; EasyDDNS; NTP; TLS v1.2; QoS; IPv4; SSH; Unicast; Multicast; ARP; FTP; |
| System compatibility | P2P (Mutually exclusive with Profile G); ONVIF (Profile S/T/G), SDK; CGI, MILSTONE |
| Remote connection | ≤2 |
| Client | Easy7 VMS |
| Mobile client | EasyLive Plus |
| Web | IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+ |
| Interface | |
| Communication interface | 1 RJ45 (10/100 Base-T) |
| Built-in Mic | 1x |
| Reset button | √ |
| On-board storage | Support microSD/microSDHC/microSDXC card, up to 512GB |
| RTC | √ |
| General | |
| Web client language | 20 languages Simple Chinese / Traditional Chinese / English / Spanish / Korean / Italian / Turkish / Russian / Thai / French / Polish / Dutch / Hebrew / Arabic / Vietnamese / German / Ukrainian / Portuguese / Albanian /Greek |
| Operating temperature | -35°C~65°C |
| Operating humidity | ≤95% RH |
| Storage temperature | -35°C~65°C |
| Storage humidity | 10-95% RH (non-condensing) |
| Power supply | DC12V ± 25%, max 6W; PoE: IEEE 802.3af, max. 7W |
| Protection | Surge 4000V; ESD 6000V; IP67 |
| Dimensions | 161 (L) x 68 (W) x 66 (H) mm |
| Package dimensions | 215 (L) x 95 (W) x 120 (H) mm |
| Gross weight | 0.614 kg |
