Tiandy TC-P3601 Spec: 7/I/O Video Intercom Kit
Tiandy Video Intercom Kit | Plug & Play
SKU
TC-P3601_SPEC7
Tiandy TC-P3601 Video intercom kit
- Supports Power over Ethernet (PoE) or can be configured with an external DC 12V power supply. The product itself does not include a power source;
- The access control intercom system is suitable for the visual management of access control in residential and villa areas;
- Plug & Play;
- User friendly interface;
- Standard PoE;
- One touch calling;
- Remote unlocking;
- CCTV integration
| SKU | TC-P3601_SPEC7 |
|---|---|
| Brand | Tiandy |
| EANcode | 6976642047694 |
| TC-P3601 Spec:7/I/O | |
| Model | Single button villa panel |
| CPU, RAM, ROM | V3LP ROM 128MB RAM 64MB |
| CMF | |
| Colour | Black |
| Material | Aluminum panel + tempered glass + Plastic nameplate button + Plastic cover |
| Finishing | Die-casting and painting |
| Video | |
| Pixels | 2MP |
| Angle | 110° (H); 67° (V); 127° (D) |
| Video codec | H.264 |
| Video resolution | Up to 1080P |
| FPS | 25 |
| WDR | - |
| Night vision | White LEDs |
| Audio | |
| Microphone | Yes |
| Speaker | Yes |
| Narrowband audio codec | G.711 |
| Full duplex | Yes |
| Aperture type | Fixed |
| Access | |
| RFID card reader | 13.56 MHz (NFC) and 125kHz |
| BLE | - |
| Wiegand | Yes |
| White LEDs | 2 |
| White light distance | Tot 30 |
| Network | |
| WiFi | N/A |
| Ethernet | Single ethernet port |
| Hardware interface | |
| Relay | 2 |
| Power unlock | - |
| RS485 | Yes |
| Tamper alarm | Yes |
| Alarm input | 2 |
| Alarm output | 2 |
| Door sensor | Yes |
| Exit button | Yes |
| Reset | Yes |
| Micro SD card | - |
| Power | |
| PoE | Yes |
| DC power supply | 12V/1A |
| Power consumption | < 10W |
| Other | |
| IP/IK level | IP65 / IK08 |
| Indicator light | Yes |
| Nameplate | Yes |
| IR sensor | - |
| Motion detection | - |
| Photoresistor | Yes |
| General | |
| Installation | Surface mount |
| Working temperature | -40°C~55° |
| Model | 7 inch Linux indoor monitor |
| Solution | RAM 128MB ROM 128MB System Linux |
| Design | Colour: Black and dark gray |
| Material | Plastic |
| Screen | |
| Type | TFT |
| Resolution | 1024x600 |
| Audio | |
| Microphone | Yes |
| Speaker | Yes |
| Narrowband audio codec | G.711 |
| Video | |
| Camera | - |
| Network | |
| WiFi | Yes |
| Ethernet | Single ethernet port |
| Hardware interface | |
| Relay | 1 |
| RS485 | Yes |
| Tamper alarm | - |
| Alarm zones | 8 |
| 12V output | - |
| Doorbell in | Yes |
| Reset | - |
| Micro USB | For debug only |
| Micro SD card | Yes |
| Power | |
| PoE | Yes |
| DC power supply | 12V |
| Power consumption | < 6W |
| Other | |
| Languages | 15 |
| General | |
| Installation | Surface mount |
| Working temperature | -10°C~55° |
