Foscam VD1, 4MP Dual-Band wifi video doorbell
This product is End of Life. At this moment there is no alternative or successor available.
SKU
VD1
Related Products
Check items to add to the cart or
This product is End of Life. At this moment there is no alternative or successor available.
Foscam VD1 Video Doorbell
- 4MP HD Color CMOS Sensor
- Angle of view: Diagonal 170°, Horizontal 152°, Vertical 81°
- Image compression H.264+/H.264
- Night vision up to 5m
- Built-in microphone, supports 2-way audio
- 2.4GHz & 5GHz Dual-Band wifi
- Motion Detection, Sound Detection & Face Detection with alerts sent to your phone/tablet
- Face Recognition: support up to 20 family members (video subscription)
- Works with Amazon Alexa and Google Assistant
- Foscam Cloud Service
- Supports up to 512GB Micro SD card for local storage
- Free 7-Day Foscam Cloud for 3 months
- Works with existing chime
| SKU | VD1 |
|---|---|
| Brand | Foscam |
| EANcode | 6954836045817 |
| Foscam Video Doorbell VD1 | |||||||
| Image Sensor | Sensor | High Definition Color CMOS Sensor | |||||
| Display Resolution | 2560*1440 (4.0M Pixels) | ||||||
| Min. Illumination | 0 Lux (Without IR Illuminator) | ||||||
| Lens | Focal length | f1.9mm | |||||
| Aperture | F 2.0 | ||||||
| Angle of view | Diagonal:170°, Horizontal:152°, Vertical:81° | ||||||
| DORI | DORI | Detect: 34.5m Observe: 13.7m Recognize: 6.9m Identify: 3.5m |
|||||
| Video | Image Compression | H.264+/H.264 | |||||
| Image Frame Rate | Max 25fps (2K) | ||||||
| Resolution | 2K (2560x1440), 1080P (1920x1080), 720P (1280 x 720) | ||||||
| Stream | Dual stream | ||||||
| HDR | Support HDR | ||||||
| Flip image | Flip and mirror | ||||||
| Infrared mode | 1pcs 850nm SMD IR-LEDs | ||||||
| Night mode | Manual and automatic modes | ||||||
| Night visibility | 5 m | ||||||
| Audio | Input/Output | Built-in mic and speaker, support full duplex 2-way Audio | |||||
| Audio Compression | AAC | ||||||
| Network | Ethernet | Transfer via Type C to RJ45 | |||||
| Wireless Standard | 2.4GHz&5GHz, IEEE802.11b/g/n/ac | ||||||
| Wireless Security | WPA, WPA2 | ||||||
| Remote Access | P2P | ||||||
| Wifi configuration mode | Support scan QR code , sound wave to add camera | ||||||
| Network Protocol | IP, TCP, UDP, SMTP, FTP, RTSP | ||||||
| Other features | Motion Detection | Alarm via E-Mail, FTP and Foscam app when an event is detected | |||||
| Sound Detection | Alarm via E-Mail, FTP and Foscam app when an event is detected | ||||||
| Face Detection | Alarm via E-Mail, FTP and Foscam app when an event is detected | ||||||
| Face Recognition | Face recognition of max 20 persons (support only with Foscam Cloud) | ||||||
Human Detection  |
√ | ||||||
| Amazon Alexa |
√ | ||||||
| Google Assistant |
√ | ||||||
| Homey |
√ | ||||||
| Privacy Block | Yes | ||||||
| HDR | Improve image clarity in complex scenario | ||||||
| Zoom | 20x digital zoom function | ||||||
| Storage | Support max 512GB Micro SD card storage, local and FTP storage, Foscam Cloud storage | ||||||
| Visitors leave a message | Support the push of guest messages to the APP | ||||||
| Power | Power Supply | AC8~24V, USB C 5V, DC12~30V | |||||
| Power Consumption | 8 Watts (Max.) | ||||||
| Physical | Dimension(LxWxH) | 115(L)x45 (W)x25 (H) mm | |||||
| Net Weight | 125g | ||||||
| Accessories | Power Kit | 1pcs (work with existing electronic chime ) | |||||
| Leveler | 1pcs (Pre-install the Leveler on the mounting plate) | ||||||
| Mounting bracket | Flat Mounting Plate*2pcs, Horizontal Wedge*1pcs, Vertical Wedge*1pcs | ||||||
| Connector | U-type Connector*1pcs,Fork Connector*1pcs | ||||||
| Doorbell Wire Extenders and Nuts | With 1pcs extra screw for backup (for AC power of Doorbell), pre-install 2 Wire Extenders on the Doorbell bod | ||||||
| L-shape Screwdriver | 1pcs | ||||||
| Screws | Wall Mount Screws*1sets,Anti-theft Screws*2pcs | ||||||
| Environment | Waterproof | IP65 | |||||
| Operating Temperature | -20°C~ 50°C (-4°F ~ 122°F) | ||||||
| Operating Humidity | 20% ~ 85% non-condensing | ||||||
| Storage Temperature | -20°C ~ 60°C (-4°F ~ 140°F) | ||||||
| Storage Humidity | 0% ~ 90% non-condensing | ||||||
| Certification | CE, FCC, RoHS, WEEE | ||||||
